E37X351CPN472MDD0U
United Chemi-Con- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 350V SCREW
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$55.192
Quote It
Technical Details
- Series:U37X
- Package:Bulk
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:350 V
- ESR (Equivalent Series Resistance):23mOhm @ 120Hz
- Lifetime @ Temp.:15000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:13.8 A @ 120 Hz
- Ripple Current @ High Frequency:19.458 A @ 10 kHz
- Impedance:-
- Lead Spacing:1.126" (28.60mm)
- Size / Dimension:2.500" Dia (63.50mm)
- Height - Seated (Max):5.157" (131.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
