DCMC692T200BC2B
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6900UF 200V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet DCMC692T200BC2B Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$62.54432
- 44$62.54432
Quote It
Technical Details
- Series:DCMC
- Package:Bulk
- Part Status:Active
- Capacitance:6900 µF
- Tolerance:-10%, +50%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):28.5mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:9.7 A @ 120 Hz
- Ripple Current @ High Frequency:12.222 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.875" (22.22mm)
- Size / Dimension:2.000" Dia (50.80mm)
- Height - Seated (Max):4.125" (104.78mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
