HSEC8-109-01-S-DV-A-L2
Samtec, Inc.- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 18POS 0.031
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet HSEC8-109-01-S-DV-A-L2 Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$5.38
Quote It
Technical Details
- Series:Edge Rate™ HSEC8
- Package:Tray
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:9
- Number of Positions:18
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.031" (0.80mm)
- Read Out:Dual
- Features:Board Guide, Latches
- Mounting Type:Surface Mount
- Termination:Solder
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Contact Type:Cantilever
- Color:Black
- Flange Feature:-
- Operating Temperature:-55°C ~ 125°C
