MS3454W36-7P
Amphenol Aerospace Operations
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MALE 47POS GOLD CRIMP
- CategoryCircular Connectors
- Datasheet MS3454W36-7P Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$269.4
- 5$241.366
- 10$227.43701
- 25$213.9444
Quote It
Technical Details
- Series:Military, MIL-DTL-5015
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle, Male Pins
- Number of Positions:47 (Power)
- Shell Size - Insert:36-7
- Shell Size, MIL:-
- Mounting Type:Panel Mount
- Mounting Feature:Bulkhead - Front Side Nut
- Termination:Crimp
- Fastening Type:Threaded
- Orientation:N (Normal)
- Shell Material:Aluminum
- Shell Finish:Olive Drab Cadmium
- Contact Finish - Mating:Gold
- Color:Olive Drab
- Ingress Protection:Fluid Resistant
- Material Flammability Rating:-
- Features:-
- Shielding:Unshielded
- Current Rating (Amps):13A, 23A
- Voltage Rating:-
- Cable Opening:-
- Operating Temperature:-55°C ~ 175°C
