UTGX714D7P32

Technical Details

• Series:UTGX
• Package:Bag
• Part Status:Active
• Connector Type:Receptacle, Male Pins
• Number of Positions:7 (6 + PE)
• Shell Size - Insert:14-7
• Shell Size, MIL:-
• Mounting Type:Panel Mount, Through Hole
• Mounting Feature:Bulkhead - Front Side Nut
• Termination:Solder
• Fastening Type:Bayonet Lock
• Orientation:N (Normal)

• Shell Material:Polyamide (PA), Nylon
• Shell Finish:-
• Contact Finish - Mating:-
• Color:Black
• Ingress Protection:IP68/IP69K - Dust Tight, Water Resistant, Waterproof
• Material Flammability Rating:UL94 V-0
• Features:Board Lock, UV Resistant
• Shielding:Unshielded
• Current Rating (Amps):12A
• Voltage Rating:600V
• Cable Opening:-
• Operating Temperature:-40°C ~ 105°C
