- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSG MALE 20POS PNL MNT
- CategoryCircular Connectors - Housings
- Datasheet HDP24-18-20PE Datasheet
-
ECAD Model
- Share
In Stock: 378
Can ship immediately
Pricing:
- 1$12.51
- 10$11.37127
- 25$11.08706
- 50$10.23414
- 100$9.66558
- 250$8.81275
- 500$8.24417
- 1,000$7.5619
Quote It
Technical Details
- Series:HDP20
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Male Pins
- Number of Positions:20
- Shell Size - Insert:18-20
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:16 (2), 20 (18)
- Mounting Type:Panel Mount
- Mounting Feature:Bulkhead - Front Side Nut
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-1
- Features:-
- Shielding:Unshielded
