- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSG FMALE 29POS PNL MT
- CategoryCircular Connectors - Housings
- Datasheet HDP24-24-29SE Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$18.24
- 10$16.93316
- 25$15.1961
- 50$14.76183
- 100$13.02515
- 250$12.1568
- 500$11.8963
Quote It
Technical Details
- Series:HDP20
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Female Sockets
- Number of Positions:29
- Shell Size - Insert:24-29
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:12 (4), 16 (19), 20 (6)
- Mounting Type:Panel Mount
- Mounting Feature:Bulkhead - Front Side Nut
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-1
- Features:Dust Cap
- Shielding:Unshielded
