JN2AW15PL1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSNG MALE 15POS PNL MT
- CategoryCircular Connectors - Housings
- Datasheet JN2AW15PL1 Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$17.68542
- 24$17.68542
Quote It
Technical Details
- Series:JN2W
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Male Pins
- Number of Positions:15
- Shell Size - Insert:W
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:22
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Zinc Alloy
- Shell Finish:Zinc
- Housing Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:-
- Shielding:Unshielded
