TEL 10-2410

Technical Details

• Series:TEL 10 (10W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):36V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):2.7A
• Power (Watts):8.9 W

• Voltage - Isolation:1.8 kV
• Applications:ITE (Commercial)
• Features:OCP, SCP
• Operating Temperature:-40°C ~ 78°C
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:16-DIP Module, 6 Leads
• Size / Dimension:0.94" L x 0.54" W x 0.31" H (23.8mm x 13.7mm x 8.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:cURus
• Standard Number:-
