PDS1-S24-S15-M-TR

Technical Details

• Series:PDS1-M (1W)
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):67mA
• Power (Watts):1 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:82%
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module, 5 Leads
• Size / Dimension:0.50" L x 0.33" W x 0.29" H (12.7mm x 8.3mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:EN, UL
• Standard Number:55024; 55032 Class A; 60950-1
