AM15E-4824DZ
DComponents
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 24V -24V 15W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$23.72
Quote It
Technical Details
- Series:AM15E-Z (15W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):36V
- Voltage - Input (Max):72V
- Voltage - Output 1:24V
- Voltage - Output 2:-24V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):310mA, 310mA
- Power (Watts):15 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:-
- Operating Temperature:-40°C ~ 70°C (With Derating)
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:5-DIP Module
- Size / Dimension:2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CE, cULus, cURus
- Standard Number:-
