TDL 3-4813

Technical Details

• Series:TDL 3 (3W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):200mA
• Power (Watts):3 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OCP, SCP
• Operating Temperature:-40°C ~ 70°C
• Efficiency:86%
• Mounting Type:Through Hole
• Package / Case:7-DIP Module, 4 Leads
• Size / Dimension:0.55" L x 0.55" W x 0.31" H (14.0mm x 14.0mm x 8.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
