MX44002NF1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER BRD EDGE 2POS 3.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX44002NF1 Datasheet
-
ECAD Model
- Share
In Stock: 484
Can ship immediately
Pricing:
- 1$4.85
- 10$4.656
- 100$3.88
- 500$3.298
- 1,350$2.813
Quote It
Technical Details
- Series:MX44
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.138" (3.50mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Board Edge, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:-
- Insulation Height:0.465" (11.80mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:Waterproof
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):3A
- Voltage Rating:-
