ATM13-12PA-12PB-BM03
Tuchel / Amphenol
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 12POS
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 364
Can ship immediately
Pricing:
- 1$19.68
- 10$18.38537
- 25$16.65128
- 50$16.21765
- 100$14.48315
- 250$13.61589
- 500$13.35572
Quote It
Technical Details
- Series:ARMORIPX™ ATM
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:12, 12
- Number of Rows:2
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Snap-In; Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.112" (2.84mm)
- Overall Contact Length:-
- Insulation Height:1.378" (35.00mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:Mounting Flange, Sealed
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:IP67
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):7.5A
- Voltage Rating:-
