IL-Y-3P-S15L2-EF
JAE Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 3POS 1.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet IL-Y-3P-S15L2-EF Datasheet
-
ECAD Model
- Share
In Stock: 1,629
Can ship immediately
Pricing:
- 1$0.41
- 10$0.385
- 100$0.2695
- 500$0.231
- 1,000$0.1925
- 5,000$0.165
- 10,000$0.154
Quote It
Technical Details
- Series:IL-Y
- Package:Bulk
- Part Status:Not For New Designs
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.059" (1.50mm)
- Number of Positions:3
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Kinked Pin, Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.118" (3.00mm)
- Contact Length - Post:0.106" (2.69mm)
- Overall Contact Length:-
- Insulation Height:0.148" (3.75mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Brown
- Current Rating (Amps):1A per Contact
- Voltage Rating:-
