1-178317-2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 8POS 3.81MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-178317-2 Datasheet
-
ECAD Model
- Share
In Stock: 2,044
Can ship immediately
Pricing:
- 1$3.61
- 10$3.46425
- 100$2.88722
- 500$2.45417
- 1,000$2.09326
- 5,000$1.87672
Quote It
Technical Details
- Series:Dynamic D-3100
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Tab
- Pitch - Mating:0.150" (3.81mm)
- Number of Positions:8
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:-
- Contact Length - Post:0.150" (3.81mm)
- Overall Contact Length:-
- Insulation Height:0.850" (21.59mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:15.0µin (0.38µm)
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic, Polyester, Glass Filled
- Features:Board Lock
- Operating Temperature:-55°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:250V
