In Stock: 2,164

Can ship immediately

Pricing:
  • 1$2.04

Quote It

Technical Details

  • Series:WR-MM
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:22
  • Number of Rows:2
  • Row Spacing - Mating:0.059" (1.50mm)
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.142" (3.60mm)
  • Contact Shape:Rectangular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyamide (PA6T), Nylon 6T
  • Features:Pick and Place
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Red
  • Current Rating (Amps):1.5A per Contact
  • Voltage Rating:100VAC

Related Products


474126

MIBR M 03POS VERT P SMT KS

  • 1: $2.88000

2842163-7

14P,2MM,BRK HDR,DRRT,2.8,0.38AU,

  • 1: $1.96000

2842116-8

8P,2MM,BRK HDR,SRRT,2.8,0.76AU,T

  • 1: $1.96000

1-2842150-0

20P,2MM,BRK HDR,DRRT,2.8,0.1AU,T

  • 1: $1.97000

2842168-8

8P, AMPMODU 2MM, DOUBLE ROW SHRO

  • 1: $1.98000

0702461003

CONN HEADER VERT 10POS 2.54MM

0702461003 Datasheet
  • 1: $2.02000
  • 3600: $1.04888

1-2355184-0

10P,2MM,BRK HDR,SRVT,2.8,0.76AU,

  • 1: $2.03000

MX34016NF3

CONN PIN HEADER 16 POS R/A

  • 1: $2.05000

ESMC-M-68-SGS-SMT-B-PP-T/R

CONN HEADER VERT SMT 68POS 1.27M

  • 1: $2.95000

1511200504
