- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 8POS
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 249
Can ship immediately
Pricing:
- 1$11.25
- 125$9.04648
Quote It
Technical Details
- Series:DT
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:8
- Number of Rows:2
- Row Spacing - Mating:0.360" (9.14mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:-
- Insulation Height:1.185" (30.10mm)
- Contact Shape:Circular
- Contact Finish - Mating:-
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:-
- Contact Material:-
- Insulation Material:Plastic
- Features:Mounting Flange
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:IP68/IP6K9K
- Material Flammability Rating:-
- Insulation Color:Brown
- Current Rating (Amps):-
- Voltage Rating:250VDC
