In Stock: 1,424

Can ship immediately

Pricing:
  • 1$2.25
  • 1,000$1.40096
  • 2,000$1.35975
  • 3,000$1.31854
  • 5,000$1.26086

Quote It

Technical Details

  • Series:High Performance Interconnect (HPI)
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.049" (1.25mm)
  • Number of Positions:10
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 3 Wall
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:-
  • Contact Length - Mating:-



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.187" (4.75mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:150.0µin (3.81µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Thermoplastic
  • Features:Solder Retention
  • Operating Temperature:-25°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Natural
  • Current Rating (Amps):1A
  • Voltage Rating:125V

Related Products


1-338728-4

CONN HEADER SMD 14POS 2.54MM

1-338728-4 Datasheet
  • 1: $2.27000
  • 7500: $1.27024

1054301105

CONN HEADER SMD R/A 5POS 2.5MM

  • 1: $2.27000

5-104362-5

CONN HEADER VERT 6POS 2.54MM

5-104362-5 Datasheet
  • 1: $2.29000
  • 30: $1.94792
  • 120: $1.77838

1054302104
