5810120011
Vitelec / Cinch Connectivity Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 20POS 3.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 5810120011 Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$14.53
- 10$13.20726
- 25$12.87728
- 50$11.88653
- 100$11.22617
- 250$10.23562
- 500$9.57526
- 1,000$8.78282
Quote It
Technical Details
- Series:ModICE® MX
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.138" (3.50mm)
- Number of Positions:20
- Number of Rows:2
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:-
- Contact Length - Post:0.130" (3.30mm)
- Overall Contact Length:-
- Insulation Height:1.610" (40.90mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polymer, Glass Filled
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:IP67, IP69K
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):10A
- Voltage Rating:-
