5810148007
Vitelec / Cinch Connectivity Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 48POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 5810148007 Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$26.27
- 10$23.71471
- 100$20.59079
- 500$18.88673
Quote It
Technical Details
- Series:ModICE® SE
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:48
- Number of Rows:3
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Threaded
- Contact Length - Mating:-
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:-
- Insulation Height:-
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polymer, Glass Filled
- Features:Ferrite Filter
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:IP67/IP69K - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):10A
- Voltage Rating:-
