0787884623
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- Description2MM DR MGRID VREC SMT CAP/TUBE/P
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$2.15487
Quote It
Technical Details
- Series:Milli-Grid 78788
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Female Socket
- Style:Board to Board
- Number of Positions:46
- Number of Positions Loaded:All
- Pitch - Mating:0.079" (2.00mm)
- Number of Rows:2
- Row Spacing - Mating:0.079" (2.00mm)
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:98.4µin (2.50µm)
- Insulation Color:Black
- Insulation Height:0.183" (4.65mm)
- Contact Length - Post:-
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:7.15mm, 8.35mm
- Ingress Protection:-
- Features:Pick and Place
- Current Rating (Amps):1A
- Voltage Rating:125VAC
