1415200000

Technical Details

• Series:Omnimate RSV
• Package:Bulk
• Part Status:Obsolete
• Connector Type:Receptacle
• Contact Type:Female Socket
• Style:Board to Board or Cable
• Number of Positions:9
• Number of Positions Loaded:All
• Pitch - Mating:0.197" (5.00mm)
• Number of Rows:3
• Row Spacing - Mating:0.197" (5.00mm)
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Latch Holder

• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:-
• Insulation Color:Gray
• Insulation Height:0.563" (14.30mm)
• Contact Length - Post:0.177" (4.50mm)
• Operating Temperature:-20°C ~ 120°C
• Material Flammability Rating:UL94 V-0
• Contact Finish - Post:Tin
• Mated Stacking Heights:-
• Ingress Protection:-
• Features:-
• Current Rating (Amps):-
• Voltage Rating:-
