HLE-120-02-F-DV-BE

Technical Details

• Series:HLE
• Package:Tube
• Part Status:Active
• Connector Type:Receptacle, Bottom Entry
• Contact Type:Female Socket
• Style:Board to Board
• Number of Positions:40
• Number of Positions Loaded:All
• Pitch - Mating:0.100" (2.54mm)
• Number of Rows:2
• Row Spacing - Mating:0.100" (2.54mm)
• Mounting Type:Surface Mount
• Termination:Solder
• Fastening Type:Push-Pull

• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:3.00µin (0.076µm)
• Insulation Color:Black
• Insulation Height:0.144" (3.66mm)
• Contact Length - Post:-
• Operating Temperature:-55°C ~ 125°C
• Material Flammability Rating:-
• Contact Finish - Post:Tin
• Mated Stacking Heights:-
• Ingress Protection:-
• Features:-
• Current Rating (Amps):4.1A per Contact
• Voltage Rating:400VAC
