- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MALE 55POS GOLD CRIMP
- CategoryCircular Connectors
- Datasheet MS24264R22B55PN Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$81.9
- 10$74.71422
- 25$68.182
- 50$60.2892
- 100$56.96299
Quote It
Technical Details
- Series:Military, MIL-DTL-26500
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle, Male Pins
- Number of Positions:55 (Power)
- Shell Size - Insert:22-55
- Shell Size, MIL:H
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Termination:Crimp
- Fastening Type:Bayonet Lock
- Orientation:N (Normal)
- Shell Material:Aluminum
- Shell Finish:Anodized
- Contact Finish - Mating:Gold
- Color:-
- Ingress Protection:Environment Sealed
- Material Flammability Rating:-
- Features:-
- Shielding:Unshielded
- Current Rating (Amps):-
- Voltage Rating:-
- Cable Opening:-
- Operating Temperature:-55°C ~ 200°C
