PC730-2C-C3-24A

Technical Details

• Series:-
• Package:Bag
• Part Status:Active
• Mounting Type:Chassis Mount
• Coil Voltage:24VAC
• Contact Form:DPDT (2 Form C)
• Contact Rating (Current):30 A
• Switching Voltage:330VAC, 36VDC - Max
• Coil Current:500 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:Quick Connect - 0.250" (6.3mm)
• Seal Rating:-
• Coil Insulation:Class B
• Must Operate Voltage:19 VAC
• Must Release Voltage:7 VAC
• Operate Time:25 ms
• Release Time:15 ms
• Operating Temperature:-25°C ~ 55°C
• Contact Material:Silver Cadmium Oxide (AgCdO)
• Relay Type:General Purpose
