ADG211AKN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD SPST SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG211AKN Datasheet
-
ECAD Model
- Share
In Stock: 20,450
Can ship immediately
Pricing:
- 1$2.24
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):115Ohm
- Channel-to-Channel Matching (ΔRon):5.75Ohm
- Voltage - Supply, Single (V+):15V
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):600ns, 450ns
- -3db Bandwidth:-
- Charge Injection:20pC
- Channel Capacitance (CS(off), CD(off)):5pF, 5pF
- Current - Leakage (IS(off)) (Max):5nA
- Crosstalk:-80dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
