TA-2157CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLO= 0.938, SO= 0.593, W= 0.045
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 420
Can ship immediately
Pricing:
- 1$3.54
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Stainless Steel
- Wire Diameter:0.045" (1.14mm)
- Diameter - Outside:-
- Diameter - Inside:0.500" (12.70mm)
- Diameter - Small Outside:0.593" (15.06mm)
- Diameter - Large Outside:0.938" (23.83mm)
- Free Length:0.630" (16.00mm)
- Max Load:-
- Rate:7.8 lbs/in
- End Style:Closed
- Finish:None
