3309CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O=1.094,L= 2.50,W= .140
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 2,187
Can ship immediately
Pricing:
- 1$4.65
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.140" (3.56mm)
- Diameter - Outside:1.094" (27.79mm)
- Diameter - Inside:0.814" (20.68mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:2.500" (63.50mm)
- Max Load:-
- Rate:91.0 lbs/in
- End Style:Closed & Ground
- Finish:Zinc
