UC2526ADWTR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG CTRLR MULT TOP 18SOIC
- CategoryPMIC - Voltage Regulators - DC DC Switching Controllers
-
ECAD Model
- Share
In Stock: 3,184
Can ship immediately
Pricing:
- 1$2.95
- 2,000$1.40049
- 6,000$1.34784
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Output Type:Transistor Driver
- Function:Step-Up, Step-Up/Step-Down
- Output Configuration:Positive
- Topology:Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
- Number of Outputs:2
- Output Phases:1
- Voltage - Supply (Vcc/Vdd):7V ~ 35V
- Frequency - Switching:1Hz ~ 600kHz
- Duty Cycle (Max):49%
- Synchronous Rectifier:Yes
- Clock Sync:Yes
- Serial Interfaces:-
- Control Features:Enable, Frequency Control, Reset, Soft Start
- Operating Temperature:-25°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:18-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:18-SOIC
