MX7847AN+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 24DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MX7847AN+ Datasheet
-
ECAD Model
- Share
In Stock: 26,534
Can ship immediately
Pricing:
- 1$23.13
- 15$21.33704
- 30$20.54936
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:4µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±11.4V ~ 16.5V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-DIP (0.300", 7.62mm)
- Supplier Device Package:24-PDIP
- Mounting Type:Through Hole
