IRFTS9342TRPBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 30V 5.8A 6TSOP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRFTS9342TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 820
Can ship immediately
Pricing:
- 1$0.5
- 3,000$0.20598
- 6,000$0.19402
- 15,000$0.18207
- 30,000$0.1737
Quote It
Technical Details
- Series:HEXFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:5.8A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:40mOhm @ 5.8A, 10V
- Vgs(th) (Max) @ Id:2.4V @ 25µA
- Gate Charge (Qg) (Max) @ Vgs:12 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:595 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):2W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:6-TSOP
- Package / Case:SOT-23-6
