MC33269D-5.0G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 5V 800MA 8SOIC
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet MC33269D-5.0G Datasheet
-
ECAD Model
- Share
In Stock: 15,437,256
Can ship immediately
Pricing:
- 1$0.86
- 98$0.71223
- 196$0.5813
- 588$0.45953
- 1,078$0.36761
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):20V
- Voltage - Output (Min/Fixed):5V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.35V @ 800mA
- Current - Output:800mA
- Current - Quiescent (Iq):-
- Current - Supply (Max):-
- PSRR:55dB (120Hz)
- Control Features:-
- Protection Features:Over Temperature, Short Circuit
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
