TPS75315QPWP
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 1.5V 1.5A 20HTSSOP
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$5.9
- 10$5.29623
- 70$5.00736
- 140$4.33966
- 560$3.69429
- 1,050$3.11567
- 2,520$2.95988
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):1.5V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.30V @ 1.5A
- Current - Output:1.5A
- Current - Quiescent (Iq):125 µA
- Current - Supply (Max):-
- PSRR:63dB (100Hz)
- Control Features:Enable, Power Good, Reset Output
- Protection Features:Over Current, Over Temperature, Reverse Polarity
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:20-PowerTSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-HTSSOP
