AP1154ADL21
Asahi Kasei Microdevices / AKM Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 2.1V 1A 8HSOP
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet AP1154ADL21 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):14V
- Voltage - Output (Min/Fixed):2.1V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.67V @ 1A
- Current - Output:1A
- Current - Quiescent (Iq):624 µA
- Current - Supply (Max):1.8 mA
- PSRR:80dB (1kHz)
- Control Features:Current Limit, Enable
- Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package:8-HSOP
