70F566AI-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6UH 637MA 492MOHM TH
- CategoryFixed Inductors
- Datasheet 70F566AI-RC Datasheet
-
ECAD Model
- Share
In Stock: 124
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:70F
- Package:Bulk
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Iron
- Inductance:5.6 µH
- Tolerance:±10%
- Current Rating (Amps):637 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):492mOhm Max
- Q @ Freq:41 @ 7.9MHz
- Frequency - Self Resonant:49MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.150" Dia x 0.250" L (3.81mm x 6.35mm)
- Height - Seated (Max):-
