1-2373378-0
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- Description10P, AMPMODU 2MM, DOUBLE ROW SHR
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 2,980
Can ship immediately
Pricing:
- 1$1.93
Quote It
Technical Details
- Series:AMPMODU
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:10
- Number of Rows:2
- Row Spacing - Mating:0.079" (2.00mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 2 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:0.145" (3.70mm)
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.252" (6.40mm)
- Contact Shape:Square
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:30.0µin (0.76µm)
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:-
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):2A
- Voltage Rating:125VAC/DC
Related Products
16P, AMPMODU 2MM, DOUBLE ROW SHR
- 1: $1.93000
16P,2MM,BRK HDR,DRVT,2.8,0.38AU,
- 1: $1.94000
10P, AMPMODU 2MM, DOUBLE ROW SHR
- 1: $1.95000
WR-MM MALE SMT CONNECTOR
- 1: $2.04000
MIBR M 03POS VERT P SMT KS
- 1: $2.88000
14P,2MM,BRK HDR,DRRT,2.8,0.38AU,
- 1: $1.96000
8P,2MM,BRK HDR,SRRT,2.8,0.76AU,T
- 1: $1.96000
20P,2MM,BRK HDR,DRRT,2.8,0.1AU,T
- 1: $1.97000
8P, AMPMODU 2MM, DOUBLE ROW SHRO
