3089CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .687,L= 3.31,W= .047
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 262
Can ship immediately
Pricing:
- 1$3.33
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.047" (1.19mm)
- Diameter - Outside:0.687" (17.45mm)
- Diameter - Inside:0.593" (15.06mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:3.310" (84.07mm)
- Max Load:-
- Rate:1.8 lbs/in
- End Style:Closed
- Finish:Zinc
