70F276AI-RC

Technical Details

• Series:70F
• Package:Bulk
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Iron
• Inductance:2.7 µH
• Tolerance:±10%
• Current Rating (Amps):1.091 A
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):168mOhm Max

• Q @ Freq:34 @ 7.9MHz
• Frequency - Self Resonant:74MHz
• Ratings:-
• Operating Temperature:-55°C ~ 105°C
• Inductance Frequency - Test:7.9 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.160" Dia x 0.250" L (4.06mm x 6.35mm)
• Height - Seated (Max):-
