SRR1280-271V4K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 270UH 1.2A 450MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1280-271V4K Datasheet
-
ECAD Model
- Share
In Stock: 105
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SRR1280
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:270 µH
- Tolerance:±10%
- Current Rating (Amps):1.2 A
- Current - Saturation (Isat):1.6A
- Shielding:Shielded
- DC Resistance (DCR):450mOhm Max
- Q @ Freq:20 @ 796kHz
- Frequency - Self Resonant:3.1MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.315" (8.00mm)
