F-100CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .125,L= .50,W= .016
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 353
Can ship immediately
Pricing:
- 1$4.09
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Music Wire
- Wire Diameter:0.016" (0.41mm)
- Diameter - Outside:0.125" (3.18mm)
- Diameter - Inside:0.093" (2.36mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:0.500" (12.70mm)
- Max Load:-
- Rate:6.9 lbs/in
- End Style:Closed & Ground
- Finish:None
