LM5116HJD
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG CTRLR BUCK 20CDIP
- CategoryPMIC - Voltage Regulators - DC DC Switching Controllers
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$236.72
- 18$226.71211
- 36$221.71111
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Type:Transistor Driver
- Function:Step-Down
- Output Configuration:Positive
- Topology:Buck
- Number of Outputs:1
- Output Phases:1
- Voltage - Supply (Vcc/Vdd):6V ~ 80V
- Frequency - Switching:200kHz, 535kHz
- Duty Cycle (Max):-
- Synchronous Rectifier:Yes
- Clock Sync:Yes
- Serial Interfaces:-
- Control Features:Enable, Frequency Control, Ramp, Soft Start
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Package / Case:20-CDIP (0.300", 7.62mm)
- Supplier Device Package:20-CDIP
